In its effort to address the effects of climate change in the ASAL region, Inades Formation Kenya has undertaken research on various innovations. One of such innovation are the Zai pits also known as planting pits which are water efficient farming technology used in arid and semi arid areas to maximise water utilization by crops.
Zai is probably the most renowned technology which has been developed based on indigenous knowledge (Sewadogo 2011) and traditionally used to improve poor and bare soils.
After digging the Zaipits, they are filled with organic materials such as manure, compost or dry biomass. This leads to increased microbial activities which in return increases the rate of water infiltration during the rainy season. This creates a micro-environment that increases drought resistance and improves crop yields. Zai pits are most suited for ASAL areas where infertile, encrusted soils receive low and often highly unreliable rainfall causing the small-scale farmers face constant challenge to produce enough food to feed their families and generate much needed incomes. Consequently, Zai pits as an innovation addresses issues of land degradation, soil infertility and moisture retention.
Through digging of zai pits; degraded hand-pan soils that is impossible to plough can be made productive rather than being abandoned. Zai pits play a very important role in controlling run off since the rain water is tapped in them, conveniently close to the crop roots thus playing a major role in water harvesting.
The process
[/av_textblock]
[/av_one_full][av_two_fifth first min_height=’av-equal-height-column’ vertical_alignment=’av-align-top’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
[/av_textblock]
[/av_two_fifth]
[av_three_fifth min_height= » vertical_alignment= » space= » custom_margin= » margin=’0px’ padding=’0px’ border= » border_color= » radius=’0px’ background_color= » src= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
Step 1 : The first step is digging a pit of measurement 60 cm length by 60 cm width by 30 cm or 90cm by 90cm by 30 in the farm. However, the size can still have different dimensions depending on crop to be planted and amount of rainfall the areas receives
[/av_textblock]
[/av_three_fifth][av_three_fifth first min_height=’av-equal-height-column’ vertical_alignment=’av-align-top’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
Step 2: After digging the pit, its halfway filled with organic matter of dry leaves, maize straws, etc which is to assist in conserving moisture content and increase manure content as the organic matter decomposes with time. However, the organic matter should be in a position to decompose within short time.
[/av_textblock]
[/av_three_fifth][av_two_fifth min_height= » vertical_alignment= » space= » custom_margin= » margin=’0px’ padding=’0px’ border= » border_color= » radius=’0px’ background_color= » src= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
[/av_textblock]
[/av_two_fifth]
[av_two_fifth first min_height=’av-equal-height-column’ vertical_alignment=’av-align-top’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
[/av_textblock]
[/av_two_fifth]
[av_one_half min_height= » vertical_alignment= » space= » custom_margin= » margin=’0px’ padding=’0px’ border= » border_color= » radius=’0px’ background_color= » src= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
Step 3 : The zai pit are then filled with a mixture of manure and top soil after the organic matter. The ratio of the manure to the top soil mainly depends on the level of fertility of the top soil and on average the ratio is 1:3. The filled organic matter and the manure take between 20-25 cm leaving space on top for water accumulation and mulching. The soil is then mixed evenly
[/av_textblock]
[/av_one_half][av_two_third first min_height=’av-equal-height-column’ vertical_alignment=’av-align-top’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
Step 4 : The zai pits are then irrigated incase the farming is being done during the dry season and the intended crops planted. If the farmer is planting maize crop a zai pit measuring 60cm by 60cm by 30cm takes up to five crops while those measuring 90cm by 90cm by 30cm takes 9 crops.
Functions of a Zai Pit
- Harvest rain water: The small pits acts as micro catchments that collect water and sediment, the soil placed downhill from each pit enhances their water harvesting function. The added organic material improves the infiltration and retention of water in the soil. The micro catchments help to mitigate against periods of drought that occurs frequently in ASAL regions (Zougmore et al 2004)
- Concentrate fertility: Zai pits concentrate fertility near the crop root zone, wind or runoff driven debris, including leaf litter from nearby vegetation is caught in the holes. Fertility gained from these sediments is mixed with organic or mineral fertilizer making them highly fertile. According to Sewadogo (2008) this also increases carbon, nitrogen, phosphorus and soil pH.
- Accelerated decomposition: In the semi arid tropics, termites are abundant, their activities contribute significantly to decomposition of organic matter and nutrient cycling in the soil (Mando and Brussaard 1999). In the process of decomposition added to the favourable zai pits environment that accelerates the decomposition making the zai pits to remain productive for longer period compared to areas without zai pits.
- Reduced competition: zai pits ensures that competition for moisture, manure and pesticides by weeds are highly reduced. This is because the crop is developed on “artificial environment” which is controlled and thus weeds and pesticides are disadvantaged. However, in case of growth of weeds, weeding should be done paying attention to the downhill side of each pit not to destroy the mounds of soil and reduce their water catchment function.
[/av_textblock]
[/av_two_third][av_one_third min_height=’av-equal-height-column’ vertical_alignment=’av-align-top’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
[/av_textblock]
[/av_one_third]
[av_one_half first min_height=’av-equal-height-column’ vertical_alignment=’av-align-middle’ space= » custom_margin=’aviaTBcustom_margin’ margin=’0px’ margin_sync=’true’ padding=’0px’ padding_sync=’true’ border= » border_color= » radius=’0px’ radius_sync=’true’ background_color= » src= » attachment= » attachment_size= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]

[/av_textblock]
[/av_one_half][av_one_half min_height= » vertical_alignment= » space= » custom_margin= » margin=’0px’ padding=’0px’ border= » border_color= » radius=’0px’ background_color= » src= » background_position=’top left’ background_repeat=’no-repeat’ animation= » mobile_breaking= » mobile_display= »]
[av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]

[/av_textblock]
[/av_one_half][av_textblock size= » font_color= » color= » av-medium-font-size= » av-small-font-size= » av-mini-font-size= » admin_preview_bg= »]
Par Muendo Nyamu, Agent de projet – Recherche, apprentissage et développement, Inades Formation Kenya
